W-HDM3D5G-50M, wireless extender set runs at 5GHz operation frequency to deliver HD video/audio 50 meters in open field. This device kit make wireless connection by using WHDI Technology from HD media Source Devices such as HD Disc or content player, PC, Game Console or Set-to -Box to any display Device for example LCD, Plasma or LED TV or projector. Providing outstanding and consistent picture quality equivalent to wired HDMI cable, with low latency, multi-room connection and low power consumption.

Features:

• WHDI Technology no latency
• 5.8Ghz automatic channel switching system
• Extends HDMI video and audio up to 50M (open Space)
• Supports HDMI, EDID 1.1, Support HDCP 2.0
• Supports resolution up to 3D supported HDTV / 1080Pp/60Hz, Vesa (1920 x 1080)
• Support AES 128 image encryption
• Real time compression audio is embedded within the HDMI output stream
• Suitable for use with Residential, PC presentations
• Extends IR and CEC Signals for remote control of AV Equipment
• Supporting the point to point transmission function currently which can be expanded to the multi-point to point transmission function.

Specifications:

• OPERATING FREQUENCY: 5.1GHz to 5.9 GHz
• BANDWIDTH: 20Mhz/40Mhz
• MODULATION MODE:
• Downlink Channel: OFDM 16-QAM;
• Uplink Channel: OFDM-OOK
• AUDIO FORMAT SUPPORTED: I2S; PCM; SPDIF; AC-3; DTS; Dolby 5.1/7
• DATA RATE: Forward Channel: 3Gbps(400MBS)
• SUPPORTED RESOLUTION & DISTANCE:
• HD: 480i, 480p, 576i, 576p, 720p, 1080i, 1080p
• PC: VGA (640x480), SVGA (800x600), XGA (1024x768),
• Monitor : 854x800, 1280x768, 1366x768, 1920x1080
• ANTENNA: High Performance Internal Antenna
• IMAGE DELAY: <1ms
• IR CMFS: 38KHz
• DIMENSIONS (L X W X H): 12" x 7" x 1"
• POWER SUPPLY: AC Input 100-240V,DC Output 5V

Includes:

• 5G WHDI Transmitter x 1pc
• 5G WHDI Receiver x 1pc
• HDMI Cable x 1pc
• IR Cable x 1pc
• Power Adapter x 2pcs
• Manual x 1pc
